An ideal machine for over wrapping big size boxes as single box or Multi-Pack wrapping.The machine can be fed either Manually or automatically from a production line.AW 55-SRV machines have full automatic OPP length adjustment features via servo motor,PLC & 7.3 touch screen system.This machine is normally used by for big size boxes or for clinets who have many different boxes.Machine is very user friendly with easy & short change over from box to another.Tear tape applicator and date printer device are available on this machine upon request.
0216 499 23 58
AW55-SRV SERVO SYSTEM CARTON BOX OVER WRAPPING MACHINE
OVER-WRAPPING MACHINE
AW55-SRV SERVO SYSTEM CARTON BOX OVER WRAPPING MACHINE
Technical Details
Lenght (L): Min 50 mm - Max 310 mm
Width (W): Min 50 mm - Max 210 mm
Height (H): Min 20 mm - Max 100 mm
OPP Lenght: Min 150 mm - Max 580 mm
Capacity: 10 - 30
Power: 5 KW, 380V - AC 3 Phase
Weight: 1050 kg
